Type：CX-ICM-1105B industrial conductivity meter
Illustrate：Widely used for continuous monitoring of conductivity of water and solution in thermal power plants, chemical fertilizer, metallurgy, environmental protection, pharmacy, biochemical engineering, foodstuff, running water and many other industries.
CX-ICM-1105B Industrial Conductivity Meter
Main Features
1.CX-ICM-1105B Microcomputer-based Industrial Control Instrument is a precision meter for measurement ofconductivity or resistivity of solution. With complete functions, stable performance, simple operation and otheradvantages, they are optimal instruments for industrial measurement and control.
2.The advantages of this instrument include: LCD display with back light and display of errors; automatictemperature compensation; isolated 4-20mA current output; dual relay control; adjustable delay; alarming withupper and lower thresholds; power-down memory and over ten years of data storage without backup battery.
3.According to the range of resistivity of the water sample measured, the electrode with a constant k = 0.01, 0.1,1.0 or 10 can be used by means of flow-through, immerged, flanged or pipe-based installation.
4. he clear display, simple operation and high measuring performance provide it with high cost performance.
Main Parameters
| Measuring range |
0~19.99 uS/cm 0~199.9 us/cm 0~1999 uS/cm 0~19.99mS/cm 0~199.9mS/cm,0~19.99 K/0~19.99 ms |
| Resolution | 0 01 uS/cm 0.01 ms/cm |
| Accuracy | 0.02 uS/cm; 0.0 1 ms/cm |
| Stability | ≤0.04 uS 24h; ≤0.02 M/24h |
| Standard solution | Any standard solution |
| Control range | 0~19.99mS/0~19.99K/0~19.99 ms |
| Temperature compensation | 0~65.0°C |
| Output signal | 0~5V or 4~20mA isolated protection output |
| Output control mode | On/Off relay output contacts (two sets) |
| Relay load | Max. 230V5A (AC); Min. l l5V10A (AC) |
| Current output load | Max. 500 |
| Working voltage | 230VAC l 0%, 50/60Hz |
| Protection | IP65 |
| Working condition | Ambient temperature: 5~45°C |
| Dimension | 186 x 131 x 81mm outdoor wall mounting |
